Bin Blender – Conta Blender

Bin Blender / Conta Blender

Ability To Handle Multiple Sizes Of IBC
Ability To Obtain A Homogeneous Blend Of Multiple Ingredients In An IBC Without Mechanical Intrusion.
Transfer Of Product From One To Another Machine
Containment And Ergonomic Situations Are Greatly
The Unique Clamping Arm Is Simple, Hygienic
In Compliance With cGMP Guidelines
Effective Blending With Help Of Mixing
Quick Dismantling Of Mixing Baffles For Easy To Clean Bins
Fully Automatic Operation Through Programmable Logic Controller (Optional)
Flameproof Construction (Optional)
AC VFD Variable Frequency Drive (Optional)
Pneumatic Loading System (Optional)

MODEL	AIMS–BB–50	AIMS–BB–100	AIMS–BB–200	AIMS–BB–300	AIMS–BB–500	AIMS–BB–800	AIMS–BB–1000	AIMS–BB–1200	AIMS–BB–1500	AIMS–BB–2000
Gross Capacity (Liter)	50 Liter	100 Liter	200 Liter	300 Liter	500 Liter	800 Liter	1,000 Liter	1,200 Liter	1,500 Liter	2,000 Liter
Working Capacity (Liter)	35 Liter	70 Liter	140 Liter	210 Liter	350 Liter	560 Liter	700 Liter	840 Liter	1,050 Liter	1,400 Liter
Machine RPM (Max)	20 RPM	28 RPM	16 RPM	24 RPM	16 RPM	16 RPM	16 RPM	16 RPM	12 RPM	12 RPM
Discharge Port Diameter	Ø 3″	Ø 4″	Ø 6″	Ø 6″	Ø 8″	Ø 8″	Ø 10″	Ø 10″	Ø 10″	Ø 12″
Electric Motor (HP / kW)	1 HP / 0.7 kW	2 HP / 1.5 kW	3 HP / 2.3 kW	3 HP / 2.3 kW	5 HP / 3.7 kW	7.5 HP / 5.5 kW	10 HP / 7.5 kW	12.5 HP / 9.3 kW	15 HP / 11.2 kW	20 HP / 14.5 kW
Electrical Power Supply	230 Volts ± 10% Or 440 Volts ± 10% / 50 Hz Or 60 Hz / 3 Φ Phase / A.C. Power Supply
